*NEW* EBOX DRAGSTER 72S
*NEW* EBOX DRAGSTER 72S
THE EBX Dragster is FINALLY HERE! In a world full of limp, slow, plastic failures, comes a truly HARDCORE electric minibike with more steeze than should be legal in such a miniature package. Featuring insane top speeds of up to 55 mph, the EBX is now delivered with a SERIOUS safety warning: Do Not Ride if You are Easily Frightened. Choose from 3 ballistic powertrains and multiple mind-blowing colourways. Fully re-engineered and reconsidered with a temperature protected PMSM encoder motor, 80 Amp Fardriver controller, bigger batteries, bigger brakes and 3-mode smart TFT colour display. Other exciting features are available such as bronze inverted suspension forks, an integrated LED headlight and luxury suede printed seats. The EBX range firmly cements the Dragster as the “Ultimate Wheelie Weapon” and King of the streets. .
SpecificationDetails
Frame typeFull duplex
Fork100mm Travel Inverted forks with bronze anodised fork legs and black hardened stanchions
Fork ClampsBillet 6061 T6 CNC machined triple clamps
Bar Risers6061 T6 CNC machined 35mm rise Ø22.2
Front wheel size6"
Rear wheel size6"
Front brakeHydraulic Disc (Right lever) e-moto brakes
Front discWavey rotor 180mm, 6 bolt 48mm BCD
Rear brakeHydraulic Disc (Left lever) e-moto brakes
Rear discWavey rotor 160mm, 6 bolt 48mm BCD
Front tyre145/70-6 SUNF fast SM tyres
Rear tyre145/70-6 SUNF fast SM tyres
ChainUprated performance gold 219H 108L
GearingFront 10T, Rear 55T
Max load100kg
Handlebar6061 T6 29.5" x 7", with 3 piece crossbar and bar pad
SeatLuxurious suede RS wedge seat
Motor72V EBX PMSM motor with temp feedback and encoder
Rated Power5.4KW
Peak power6.3KW (8.5hp)
Max RPM9,000
BatteryNew 72v 25 Ah battery with BMS 21700 Cells potted in steel case with QS8 connector and air breaker switch
Controller80 Amp fardriver controller
ThrottleSURRON style full twist
DisplayTFT odometer display with 3 speed modes and fault code analysis software
ConnectorsAutomotive connectors with sealed wiring harness
ChargerAC 100-240V, Output: 84V, 6A
LightLED headlight and switch
