*NEW* EBOX DRAGSTER 60R
*NEW* EBOX DRAGSTER 60R
THE EBX Dragster is FINALLY HERE! In a world full of limp, slow, plastic failures, comes a truly HARDCORE electric minibike with more steeze than should be legal in such a miniature package. Featuring insane top speeds of up to 55 mph, the EBX is now delivered with a SERIOUS safety warning: Do Not Ride if You are Easily Frightened. Choose from 3 ballistic powertrains and multiple mind-blowing colourways. Fully re-engineered and reconsidered with a temperature protected PMSM encoder motor, 80 Amp Fardriver controller, bigger batteries, bigger brakes and 3-mode smart TFT colour display. Other exciting features are available such as bronze inverted suspension forks, an integrated LED headlight and luxury suede printed seats. The EBX range firmly cements the Dragster as the “Ultimate Wheelie Weapon” and King of the streets. .
SpecificationDetails
Frame typeFull duplex
ForkRigid High Tensile
Bar RisersCast alloy 36mm rise Ø22.2
Front wheel size6"
Rear wheel size6"
Front brakeHydraulic Disc (Right lever) e-moto brakes
Front discWavey rotor 160mm, 6 bolt 48mm BCD
Rear brakeHydraulic Disc (Left lever) e-moto brakes
Rear discWavey rotor 160mm, 6 bolt 48mm BCD
Front tyre145/70-6 SUNF fast SM tyres
Rear tyre145/70-6 SUNF fast SM tyres
Chain219H 108L
GearingFront 10T, Rear 55T
Max load100kg
HandlebarHigh Tensile 2 Piece 29.5" x 7"
SeatDragster seat
Motor60V EBX PMSM motor with temp feedback and encoder
Rated Power4.5KW
Peak power5.2KW (6.7hp)
Max RPM8,500
BatteryNew 60v 26 Ah battery with BMS 18,600 Cells potted in steel case with QS8 connector and air breaker switch
Controller80 Amp fardriver controller
ThrottleSURRON style full twist
DisplayTFT odometer display with 3 speed modes and fault code analysis software
ConnectorsAutomotive connectors with sealed wiring harness
ChargerAC 100-240V, Output: 67.2V, 5A
